EPA-EST. MPG
|
City
|
Highway
|
2.0L Turbo I-4
|
22 (FWD)
22 (AWD) |
29 (FWD)
27 (AWD) |
3.6L V-6
|
19 (FWD)
19 (AWD) |
27 (FWD)
26 (AWD) |
FUEL TANK CAPACITY (approx.)
19 gal. / 72 liters (FWD)
22 gal. / 83 liters (AWD) |
ENGINES
| Type: |
2.0L Turbocharged I4 DOHC with direct injection, Active Fuel Management and automatic stop/start
|
Bore & Stroke (in. / mm):
|
3.26 x 3.63 / 83 x 92.3
|
Block Material:
|
Cast aluminum
|
Cylinder Head Material:
|
Cast aluminum
|
Valvetrain:
|
Dual overhead camshafts, four valves per cylinder with tripower system
|
Fuel Delivery:
|
Direct injection with electronic throttle control
|
Horsepower
(hp / kW @ rpm):
|
228 / 171 @ 5000
|
Torque (lb.-ft. / Nm):
|
258 / 350 @ 1500-4000
|
Type:
|
3.6L V-6 DOHC VVT with Direct Injection and automatic stop/start
|
Bore & Stroke (in / mm):
|
3.74 x 3.37 / 95 x 85.8
|
Block Material:
|
Cast aluminum w/ cast-in-place iron bore liners
|
Cylinder Head Material:
|
Cast aluminum
|
Valvetrain:
|
Dual-overhead camshafts, four valves per cylinder, continuous variable valve timing
|
Fuel Delivery:
|
Direct, high-pressure fuel injection with electronic throttle control
|
Horsepower
(hp / kW @ rpm):
|
310 / 231 @ 6600 (SAE certified)
|
Torque (lb.-ft. / Nm):
|
271 / 373 @ 5000 (SAE certified)
|
TRANSMISSION & AXLE
| Type: |
Hydra-Matic 9T60 nine-speed automatic – 2.0L
Hydra-Matic 9T65 nine-speed automatic – 3.6L
|
Gear Ratios (:1)
|
|
First
|
4.69
|
Second
|
3.31
|
Third
|
3.01
|
Fourth
|
2.44
|
Fifth
|
1.92
|
Sixth
|
1.44
|
Seventh
|
1.00
|
Eighth
|
0.75
|
Ninth
|
0.62
|
Reverse
|
2.96
|
Final Drive Ratio (:1):
|
3.47 – 2.0L Turbo
3.49 – 3.6L
|
CHASSIS & SUSPENSION
| Front Suspension: |
MacPherson strut with direct-acting stabilizer bar; Continuous Damping Control real-time damping avail. on Denali
|
Rear Suspension:
|
Five-link independent; coil springs with stabilizer bar; Continuous Damping Control real-time damping avail. on Denali
|
Steering Type:
|
Electric variable-effort power steering with Active Return Assist
|
Turning Circle (ft. / m):
|
38.7 / 11.8
|
Brake Type:
|
Four-wheel-disc, variable brake system with power assist; Duralife brake rotors and low-drag brake calipers
|
Brake Rotor Size (in / mm):
|
Front: 12.6 x 1.9 / 321 x 30
Rear: 12.4 x 0.9 / 315 x 23
|
Wheel Size:
|
17-in. aluminum (std. AT4)
18-in. aluminum (std. SLE and SLT)
20-in. aluminum (std. Denali; avail. SLE and SLT – and included with Elevation Edition)
|
Tire Size:
|
P245/65R17 all-season
P255/65R17 all-terrain
P235/65R18 all-season
P235/55R20 all-season
|
EXTERIOR DIMENSIONS
| Wheelbase (in. / mm): |
112.5 / 2858
|
Overall Length (in. / mm):
|
193.4 / 4912
|
Overall Width (in. / mm):
|
75.4 / 1915
|
Overall Height (in. / mm):
|
66.7 / 1694 (w/o luggage rack)
|
Track (in. mm):
|
64.5 / 1638 (front)
64.5 / 1638 (rear)
|
Ground Clearance (in. / mm):
|
7.2 / 183
|
INTERIOR DIMENSIONS & CARGO VOLUME
| Headroom (in / mm): |
Front: 40 / 1016 (without sunroof)
2nd row: 39.6 / 1006 (without sunroof)
3rd row: 37.2 / 945 (without sunroof)
|
Legroom (in. / mm):
|
Front: 41 / 1041
2nd row: 39.7 / 1008
3rd row: 29.7 / 754
|
Shoulder Room (in. / mm):
|
Front: 59.4 / 1509
2nd row: 58.7 / 1491
3rd row: 54.3 / 1379
|
Hip Room (in. / mm):
|
Front: 55.7 / 1415
2nd row: 53.3 / 1354
3rd row: 42.9 / 1090
|
CURB WEIGHT, CAPACITIES & CARGO VOLUME
| Curb Weight (lb. / kg): |
4155 / 1885 – SLE FWD w/ 2.0L Turbo
4342 / 1970 – SLE AWD w/ 2.0L Turbo
4207 / 1908 – SLT FWD w/ 2.0L Turbo
4394 / 1993 – SLT AWD w/ 2.0L Turbo
4303 / 1952 – SLT FWD w/ 3.6L
4493 / 2038 – SLT AWD w/ 3.6L
4495 / 2039 – AT4 w/ 3.6L
4221 / 1915 – Denali FWD w/ 2.0L Turbo
4426 / 2008 – Denali AWD w/ 2.0L Turbo
4317 / 1958 – Denali FWD w/ 3.6L
4525 / 2053 – Denali AWD w/ 3.6L
|
EPA Passenger Volume
(cu. ft. / L):
|
143.8 / 4072
|
Cargo Volume (cu. ft. / L)1:
|
79 / 2237 (behind first row – second and third rows folded)
41.7 / 1181 (behind second row – third row folded)
12.8 / 362 (behind third row)
|
Trailering Capacity
(lb. / kg)2:
|
4000 / 1814 (3.6L with trailering pkg.)
3300 / 1497 (2.0L with trailering pkg.)
|
1Cargo and load capacity limited by weight and distribution.
2Before you buy a vehicle or use it for trailering, carefully review the Trailering section of the Owner’s Manual.
SAFETY & DRIVER AWARENESS FEATURES
| Airbags1: frontal and side-impact for driver and front passenger; driver inboard seat-mounted side-impact; driver side knee; and roof-rail mounted head-curtain for all rows in outboard seating positions. Includes Passenger Sensing System |
Standard Tire Pressure Monitor System; tire pressure monitor includes tire fill alert (excludes spare tire)
|
Standard HD Rear Vision Camera2, Lane Change Alert with Side Blind Zone Alert2 and Rear Cross Traffic Alert2
|
GMC Pro Safety Plus package2 is standard. Content includes Automatic Emergency Braking, Front Pedestrian Braking, IntelliBeam headlamps, Front and Rear Park Assist, Lane Keep Assist with Lane Departure Warning, Following Distance Indicator and Forward Collision Alert
|
Technology Package2 is available on SLT and AT4. Content includes HD Surround Vision and Head-Up Display
|
Denali Technology Package2 is available on Denali. Content includes HD Surround Vision, Adaptive Cruise Control, Enhanced Automatic Emergency Braking, Rear Camera Mirror and Rear Camera Mirror Washer
|
Safety Alert Seat2 is standard on SLT, AT4 and Denali
|
1Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See your vehicle Owner’s Manual for more information.
2Read the vehicle's owner's manual for more important feature limitations and information.
